Model

ST-800

video Signnal

Support NTSC & PAL Standards (Auto Selection)

Operating System

Embedded Linux

Pentaplex Function

Simultaneous Live / Record / Playback / Network /

Backup

Video

Input Out

8

1 Composite (BNC), 1 VGA

1BNC(Spot)

Loop Out

8

Display

Speed

NTSC: 240fps / PAL: 400fps

Screen

1/4/7/8

Video Compression

Enhanced MPEG-4

Recording

Speed

NTSC: CIF(240fps), HVGA(120fps)

PAL: CIF(200fps), HVGA(100fps)

Resolution

NTSC: CIF(360x240), HVGA(720x240)

PAL: CIF(360x288), HVGA(720x288)

Serial Interface

RS-485, RS-232C (PTZ, Keyboard, POS)

System Control

PC Mouse, Key Buttons, IR Remote Controller,

Keyboard Controller, Client PC

Alam

In / Out

8/1

Audio

In / Out

4 channel (16 channel, option)

Display Settings

Brightness, Contrast, Color Adjustments, Hidden/

Covert Per Channel

Camera Title

13 Characters per Channel

Recording Modes

Continuous, Schedule, Alarm, Motion, Overwrite

Recording Adjustments

4 Levels of Resolution /

Recording Frame Rate Adjustment Per Channel

Motion Detection Per

Channel

294 Selectable Grids / 5 Sensitivity Levels

Search Modes

Time & Date, Camera, Motion, Alarm, Video Loss

Playback Modes

Forward & Reverse: Pause, Field by Field,

Normal Speed, 2x, 4x, 8x, 16x, Panorama, Motion

Power Failure Recovery

Auto Reboot while Maintaining Previous Status

Alarm Notification

Automatic E-mail

System Utility

3-Level Password

Internal Backup Device

CD-RW or DVD-RW

External Backup Device

USB2.0: Memory Stick, External HDD

Mini-player for Backup

Installing dedicated software into PC is not required to

playback files from CD or DVD

Communication Port

USB2.0, RS-232C, RS-42/485, Ethernet

Storage Capacity

Up to 1.5TB: 3 Internal

Network

LAN, WAN, Internet, PSTN, GIGA Ethernet

External Modem Support

RS232C

Remote Client Software

Multi-site / Enterprise Level Client Software or

Web Browser(IE 6.0)

Dimensions

440(W) x 430(D) x 78(H) : 2U Rack Mount Kit

Weight

7kg

Power

60W, 90~264 VAC (47Hz~63Hz)

Operating Temperature

0 ~ 40°C
